OCM 700mm Compact Expandable Container House for Guest Accommodation and Small Site Stays

Area note:Expanded external footprint and estimated internal floor area are different measurements. Occupancy figures are planning references only, not certified maximum capacities. Confirm all final dimensions, clearances, facilities and applicable local requirements against the approved drawing.

1. Scenic-area welcome or support room

A compact tourism site may need a private room for a host, a guide, or an on-duty team member without committing to a large permanent building. The 700 mm folded format makes transport planning a central part of the decision. When expanded, the layout can be reviewed for a reception counter, a small waiting area, storage, or a staff rest zone. Final furniture positions should be mapped before ordering so that doors, circulation and power points work together.

2. Field survey and remote project support

Survey teams and remote project operators often work in places where delivery access, handling equipment and temporary storage require advance coordination. A compact folded module may help the logistics plan, while the expanded interior provides a more protected working or resting environment than an open shelter. Confirm vehicle access, lifting arrangements, ground preparation and the intended duration of use before selecting finishes or insulation.

3. Small-scale guest cabin concept

For a rural property, garden stay, or small visitor destination, this model can be assessed as a limited-capacity cabin where the owner values a defined private zone. It should be designed around the actual guest experience: a clear entrance, uncluttered movement, suitable ventilation and a practical place for luggage. Whether a washroom or kitchenette is included must be agreed from the final drawing rather than inferred from the term container house.

4. Temporary site office or monitoring point

Some sites need a dedicated point for monitoring, reporting or occasional administration rather than a full-size office building. A compact expandable unit can provide a protected area for a desk, records and basic equipment. Planning should focus on sight lines, cable routes, external lighting and the position of the door relative to the site circulation plan. If several units are required, keep access, servicing and emergency routes clear.

Practical application planning: For a narrow-access project, assess the complete handling route rather than the gate width alone. Measure turning areas, overhead clearance, road restrictions and the location where lifting equipment can stand. A 700 mm folded profile is a useful data point, but the final plan still depends on the full folded length and height, the transport method and safe access to the prepared base.

Operational considerations for this use case: Before assigning the unit to a particular task, decide whether people will stay overnight, work inside during the day or use it only occasionally. Overnight accommodation normally puts more emphasis on privacy, ventilation and personal storage, while a monitoring or work room needs good lighting and equipment access. That use decision should shape the interior plan and service requirements.

(1) Folded profile designed around access planning

The 700 mm folded width is the feature most likely to distinguish this model in a project shortlist. Buyers should still assess the complete folded dimensions, truck access, turning space, unloading point and lifting method, but a narrow folded profile can simplify some transport and temporary staging discussions compared with a fully expanded footprint. It does not remove the need for proper handling equipment or route surveys.

(2) Expanded footprint for a defined compact purpose

The estimated internal floor area is about 25.9 m² after expansion, calculated from the listed internal length and width. This is substantial enough to justify a deliberate room plan, but it should not be treated as limitless space. An early furniture layout helps avoid overloading the room with oversized storage, multiple competing functions or circulation paths that make daily use awkward.

(3) A focused option for specialist small projects

Not every site needs a general-purpose family layout. This unit is better evaluated against a clear task: a guest room, a support room, a field team space or a compact stay unit. A specific use case helps the buyer and manufacturer make more useful decisions about windows, doors, insulation choice, lighting, sockets and interior finishes.

(4) Configuration decisions can be discussed before production

Door and window arrangements, insulation core choices, interior partitions and service provisions should be reviewed against the project specification. Discussing these details before manufacture reduces the chance of treating an essential feature as an afterthought. Availability and the final approved drawing should determine the order specification, not a generic product photograph.

(5) Additional value for project buyers

The model is especially relevant when the folded route is part of the project decision, not an incidental detail. By assessing the access envelope at the start, the buyer can avoid selecting a layout that looks suitable on paper but cannot be handled or placed using the available site approach. That is a project-planning advantage rather than a claim that transport constraints disappear.

(6) Long-term planning value

A use-led specification also helps keep the order focused. Buyers can direct budget toward the features that matter for the task—privacy, ventilation, work lighting, or a specific storage arrangement—instead of paying for rooms or equipment the site does not need. Any selected option should still be confirmed against the approved drawing and supply list.

# Layout, room use and occupancy planning

Because the product is compact when folded but wider after expansion, the site plan must show both conditions. Mark the delivery route, unloading zone, temporary staging point, final footprint and the space needed for the expansion operation. Do not check only whether the folded unit fits through a gate; check whether the completed house can be expanded safely without colliding with a fence, retaining wall, tree, neighbouring structure or overhead obstruction.

Inside, plan from the main activity outward. A guest room benefits from a clear circulation strip, reachable switches and sockets, controlled storage volume and a sensible furniture scale. If the unit is intended for work, reserve a usable desk wall and cable path. If it is intended for overnight stays, plan privacy, ventilation, lighting and luggage storage first. Room counts and sanitary facilities must follow the agreed layout.

The estimated internal area is 25.9 m²; this does not replace clear room measurements. The final number of occupants must match the approved bed plan, sanitary provision, circulation, local requirements and the way the unit will be used.

Site Preparation & Installation

# Site preparation, delivery and installation

The installation area should be accessible, prepared, level and designed to support the selected unit in accordance with the project design. Foundation type and bearing requirements depend on ground conditions, local engineering requirements and the approved configuration. Drainage should keep runoff away from the floor perimeter, while the route for electrical and water services should be planned before placing the module.

Installation duration depends on site readiness, crew experience, lifting equipment, weather, utility connections and the final configuration. A factory-prepared expandable structure can reduce the amount of on-site assembly compared with building every component from scratch, but a fixed completion time should not be assumed. Request the installation sequence and site checklist for the specific order.

Folded transport dimensions: 700 × 5900 × 2480 mm. Expanded external dimensions: 4810 × 5900 × 2480 mm. Confirm the final packaging data, unloading arrangement, support-base details and utility responsibilities before shipment.

Q1: How should I compare folded and expanded dimensions?

Use the listed folded transport dimensions for initial logistics review: 700 × 5900 × 2480 mm. The completed external dimensions are 4810 × 5900 × 2480 mm; the installation site must accommodate the expanded form and the space required to open the unit. Ask for final packing dimensions, gross weight and loading advice for the actual order before freight is booked.

Q2: How should the base and service routes be prepared?

The site needs an appropriate support base, a clear delivery and unloading route, space for the expansion sequence, drainage and planned utility routes where required. Foundation design depends on ground conditions, engineering and local requirements. Provide the site plan to the installation team and compare it with the supplier's instructions before arranging delivery or preparing the support base for transport width and compact guest accommodation.

Q3: Can installation time be guaranteed?

The expandable construction is intended to reduce some on-site assembly compared with building every component on location, but no fixed completion time should be assumed from the product category alone. Timing depends on the prepared base, lifting equipment, crew, weather, services, final fit-out and inspection. Ask for a project-specific installation sequence and confirm which activities are included in the supplier's scope.

Q4: How do I confirm shipment and packaging details?

OCM's sea-export packing description includes moisture-resistant wrapping and anti-collision protection; confirm the actual package for your order. The exact package, loading arrangement and included components must be confirmed for the order. Before shipment, ask for the packing list, folded dimensions, shipping weight, loading plan and any required documents. The freight forwarder should evaluate the actual cargo data and destination constraints.

Q5: What is the approximate usable floor area?

Using the listed internal length and width for the 700 mm compact folded-width reference model, the estimated internal floor area is about 25.9 m². The expanded external footprint is about 28.4 m², which includes the external dimensions rather than only the interior. These figures are estimates for comparing the transport width and compact guest accommodation concept; the final room drawing should be used to confirm clear dimensions before furniture is specified.

Q6: What occupant number should I use for early planning?

For early planning, use this guide: 1–2 people as a preliminary guest-stay planning guide; confirm the actual sleeping arrangement and local occupancy requirements. It is not a certified capacity or a promise of legal occupancy. For a project centred on transport width and compact guest accommodation, occupant planning must account for bed arrangement, furniture, ventilation, restroom capacity, movement space and the destination's applicable rules. Tell us how the unit will be used so the proposed layout can be assessed more accurately.

Q7: What is the standard layout for this unit?

The reference arrangement is: Compact expandable layout; the exact room arrangement should be confirmed against the selected drawing. Review the approved floor plan for actual room dimensions, partition positions, door swings, windows and circulation. Product images can show a sample arrangement and should not replace the drawing attached to your quotation. If a room or facility is essential, make sure it appears by name and position in the final specification.

Q8: How should I request layout changes?

Layout discussions can be based on the intended occupants, use of the rooms, preferred openings, facilities, storage and site conditions. Changes must be reviewed for technical feasibility and confirmed by OCM on an approved drawing. For this 700 mm compact folded-width reference model, do not assume every requested change is available as standard or that it leaves the reference dimensions unchanged; confirm any effect on folded size and transport.

Q9: Can I select the insulation material?

Listed insulation-core options include EPS, rock wool and PU. The suitable choice depends on destination climate, intended use, project specification, local regulations and the full wall/roof assembly. Ask OCM to confirm the material, thickness and relevant technical documents for the exact order. Do not treat the material name alone as proof of a particular fire, thermal or acoustic rating.

Q10: What local approvals should I check?

Requirements depend on the destination, intended occupancy and whether the unit is used as a residence, guest accommodation, workplace or public facility. Before purchase, check planning permission, structural design, fire safety, energy performance, sanitation, electrical work and occupancy rules with relevant local professionals or authorities. Any product-specific certificates or reports should be verified for the actual model and market.

Q11: Which details are important before ordering?

Please share the destination country, intended use, quantity, preferred layout (Compact expandable layout; the exact room arrangement should be confirmed against the selected drawing.), target occupants, insulation preference, door/window requirements, required kitchen or restroom facilities and any site-access limitations. A site sketch or photos can help where delivery access is difficult. Ask for a dimensioned drawing, material list, package details, included/excluded items and confirmation of the final configuration before ordering.

Q12: Are cooking and washing facilities part of the supply?

Kitchen and restroom facilities are not established by the stated layout and must be confirmed separately. For the specified layout (Compact expandable layout; the exact room arrangement should be confirmed against the selected drawing.), confirm the exact fixture package, cabinetry, appliances, hot-water equipment and utility connections in the approved quotation. Please identify every required item before production. If the project needs an independent kitchen or a complete bathroom, ask for a drawing and inclusion list showing the fixture arrangement, water and wastewater points, ventilation and electrical provisions.
